TMS370C742AFNT
RoHS
RoHS compliant
RoHS compliantPackage 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 8B MCU
PDF
/
Buying Options
Total Price: USD $17.43
Unit Price: USD $17.43345
≥1 USD $17.43345
≥10 USD $14.30415
≥100 USD $13.85765
≥500 USD $13.4102
≥1000 USD $12.9637
Inventory: 1339
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-LCC (J-Lead)
Number of Pins 44
Technical
Operating Temperature -40°C~105°C TA
Packaging Tube
Series TMS370
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 44
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Supply Voltage 5V
Frequency 5MHz
Base Part Number 370C742
Pin Count 44
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Memory Size 8kB
Oscillator Type Internal
Number of I/O 27
RAM Size 256 x 8
Memory Type EPROM, OTP
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Peripherals PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 8KB 8K x 8
Connectivity SCI
Supply Current-Max 45mA
Bit Size 8
Data Converter A/D 8x8b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
EEPROM Size 256 x 8
Dimensions
Height Seated (Max) 4.57mm
Length 16.585mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
