TMS320F28376SZWTS
RoHS
RoHS compliant
RoHS compliantPackage 337-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 337FBGA
PDF
/
Buying Options
Total Price: USD $64.44
Unit Price: USD $64.43565
≥1 USD $64.43565
≥10 USD $52.87035
≥100 USD $51.21735
≥500 USD $49.5653
≥1000 USD $47.91325
Inventory: 1226
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 16mm
Length 16mm
Height 1.4mm
Technical
Number of Timers 3
Number of Serial I/Os 5
Number of UART Channels 4
RAM (words) 132
Integrated Cache NO
Format FLOATING-POINT
Low Power Mode YES
Boundary Scan YES
CPU Family TMS320
Density 4 Mb
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 24x12b, 12x16b; D/A 3x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, I2C, McBSP, SCI, SPI, uPP, UART/USART, USB
Program Memory Size 512KB 256K x 16
Core Size 32-Bit Single-Core
Program Memory Type FLASH
Peripherals DMA, POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.14V~3.47V
RAM Size 66K x 16
Number of I/O 169
Oscillator Type Internal
Supply Voltage-Max (Vsup) 1.26V
Base Part Number 320F28376
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 200MHz
Terminal Pitch 0.8mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 337
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series C2000? C28x Delfino?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 337
Surface Mount YES
Package / Case 337-LFBGA
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 8 Weeks
