TMS320F28376DPTPS
RoHS
RoHS compliant
RoHS compliantPackage 176-LQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 176HQFP
PDF
/
Buying Options
Total Price: USD $100.92
Unit Price: USD $100.921045
≥1 USD $100.921045
≥10 USD $95.208537
≥100 USD $89.819371
≥500 USD $84.735259
≥1000 USD $79.938922
Inventory: 1268
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.4mm
Width 24mm
Length 24mm
Height 1.6mm
Technical
Number of Timers 6
Number of Serial I/Os 4
Number of UART Channels 4
RAM (words) 172
Boundary Scan YES
CPU Family TMS320
Density 4 Mb
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 20x12b, 9x16b; D/A 3x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, I2C, McBSP, SCI, SPI, uPP, UART/USART, USB
Program Memory Size 512KB 256K x 16
Core Size 32-Bit Dual-Core
Program Memory Type FLASH
Peripherals DMA, POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.14V~3.47V
RAM Size 86K x 16
Number of I/O 97
Oscillator Type Internal
Memory Size 512kB
Interface CAN, EBI/EMI, I2C, SCI, SPI, UART, USART, USB
Power Supplies 1.23.3V
Supply Voltage-Max (Vsup) 1.26V
Qualification Status Not Qualified
Pin Count 176
Base Part Number 320F28376
Frequency 200MHz
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 176
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series C2000? C28x Delfino?
Packaging Tray
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 176
Surface Mount YES
Package / Case 176-LQFP Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 8 Weeks
