TMS320F28374SPZPT
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Delfino? 32-bit MCU with 400 MIPS, 1xCPU, 1xCLA, FPU, TMU, 512 KB Flash, EMIF, 12b ADC 100-HTQFP -40 to 105
PDF
/
Buying Options
Total Price: USD $10.59
Unit Price: USD $10.590307
≥1 USD $10.590307
≥10 USD $10.070553
≥100 USD $9.420831
Inventory: 100
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 19 hours ago)
Physical
Mounting Type Surface Mount
Package / Case 100-TQFP Exposed Pad
Surface Mount YES
Number of Pins 100
Technical
Operating Temperature -40°C~105°C TJ
Packaging Tape & Reel (TR)
Series C2000? C28x Delfino?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.2V
Terminal Pitch 0.5mm
Frequency 200MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 320F28374
Supply Voltage-Max (Vsup) 1.26V
Oscillator Type Internal
Number of I/O 41
RAM Size 66K x 16
Voltage - Supply (Vcc/Vdd) 1.14V~3.47V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor C28x
Peripherals DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit Single-Core
Program Memory Size 512KB 256K x 16
Connectivity CANbus, I2C, McBSP, SCI, SPI, uPP, UART/USART, USB
Bit Size 32
Data Converter A/D 14x12b; D/A 3x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
Density 4 Mb
CPU Family TMS320
Boundary Scan YES
Low Power Mode YES
Format FLOATING-POINT
Integrated Cache NO
RAM (words) 132
Number of UART Channels 4
Number of Serial I/Os 5
Number of Timers 3
Dimensions
Height 1.2mm
Length 14mm
Width 14mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
