TMS320F2808GGMS
RoHS
/
Package 100-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 128KB FLASH 100BGA
PDF
/
Buying Options
Total Price: USD $20.8
Unit Price: USD $20.80215
≥1 USD $20.80215
≥10 USD $17.06865
≥100 USD $16.53475
≥500 USD $16.0018
≥1000 USD $15.4679
Inventory: 1555
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Lead, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-LFBGA
Number of Pins 100
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Series Automotive, AEC-Q100, C2000? C28x Fixed-Point
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature ALSO REQUIRES 3.3V SUPPLY
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 220
Supply Voltage 1.8V
Terminal Pitch 0.8mm
Frequency 100MHz
Base Part Number 320F2808
Pin Count 100
Operating Supply Voltage 1.8V
Supply Voltage-Max (Vsup) 1.89V
Power Supplies 1.83.3V
Interface CAN, I2C, SCI, SPI, UART, USART
Memory Size 128kB
Oscillator Type Internal
RAM Size 18K x 16
Voltage - Supply (Vcc/Vdd) 1.71V~1.89V
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Core Processor C28x
Peripherals POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 128KB 64K x 16
Connectivity CANbus, I2C, SCI, SPI, UART/USART
Bit Size 32
Data Converter A/D 16x12b
Data Bus Width 32b
PWM Channels 12
Core Architecture TMS320
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 16
Number of Programmable I/O 35
Integrated Cache NO
Number of UART Channels 2
Number of Timers 10
Number of External Interrupts 3
Barrel Shifter NO
Internal Bus Architecture MULTIPLE
Dimensions
Height 1.4mm
Length 10mm
Width 10mm
Thickness 900μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
