TMS320F28054PNT
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant GULL WING QUAD Microcontroller -40C~105C TA 60MHz 1.6mm 10K x 16
PDF
/
Buying Options
Total Price: USD $48.13
Unit Price: USD $48.1289
≥1 USD $48.1289
≥10 USD $39.49055
≥100 USD $38.2565
≥500 USD $37.02245
≥1000 USD $35.7884
Inventory: 2507
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 12mm
Height Seated (Max) 1.6mm
Technical
On Chip Program ROM Width 8
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x12b
Bit Size 32
Connectivity CANbus, I2C, SCI, SPI, UART/USART
Program Memory Size 128KB 64K x 16
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.71V~1.995V
RAM Size 10K x 16
Number of I/O 42
Oscillator Type Internal
Memory Size 128kB
Interface CAN, I2C, SCI, SPI, UART, USART
Supply Voltage-Max (Vsup) 1.995V
Operating Supply Voltage 3.3V
Pin Count 80
Base Part Number 320F28054
Frequency 60MHz
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Series C2000? C28x Piccolo?
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 80
Surface Mount YES
Package / Case 80-LQFP
Mounting Type Surface Mount
