TMS320F28052MPNT
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-Bit Piccolo F2805x C28x CISC 64KB Flash 1.8V/3.3V 80-Pin LQFP
PDF
/
Buying Options
Total Price: USD $12.24
Unit Price: USD $12.236047
≥1 USD $12.236047
≥10 USD $11.543437
≥100 USD $10.890033
≥500 USD $10.27362
≥1000 USD $9.692093
Inventory: 9067
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 80-LQFP
Surface Mount YES
Number of Pins 80
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Series C2000? C28x Piccolo?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 80
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature 1-CH BUFFRED DAC IS THERE
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Frequency 60MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 320F28052
Supply Voltage-Max (Vsup) 1.995V
Supply Voltage-Min (Vsup) 1.71V
Interface CAN, I2C, SCI, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 42
RAM Size 8K x 16
Voltage - Supply (Vcc/Vdd) 1.71V~1.995V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor C28x
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 64KB 32K x 16
Connectivity CANbus, I2C, SCI, SPI, UART/USART
Bit Size 32
Data Converter A/D 16x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
Dimensions
Height 1.6mm
Length 12mm
Width 12mm
Thickness 1.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
