TMS320F28026FPTT
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-bit Piccolo F2802x C28x RISC 32KB Flash 3.3V 48-Pin LQFP T/R
PDF
/
Buying Options
Total Price: USD $5.21
Unit Price: USD $5.21455
≥1 USD $5.21455
≥10 USD $4.2788
≥100 USD $4.14485
≥500 USD $4.0109
≥1000 USD $3.87695
Inventory: 1459
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-LQFP
Number of Pins 48
Technical
Operating Temperature -40°C~105°C TA
Number of External Interrupts 3
Number of Serial I/Os 1
Number of ADC Channels 8
Number of UART Channels 1
RAM (words) 12
Integrated Cache NO
Format FIXED-POINT
Low Power Mode YES
Boundary Scan YES
Number of Timers/Counters 3
PWM Channels YES
Data Bus Width 32b
DMA Channels NO
Has ADC YES
Data Converter A/D 13x12b
Bit Size 32
Supply Current-Max 90mA
Connectivity I2C, SCI, SPI, UART/USART
Program Memory Size 32KB 16K x 16
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.71V~1.995V
RAM Size 6K x 16
Number of I/O 22
Oscillator Type Internal
Memory Size 32kB
Interface I2C, SCI, SPI, UART, USART
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number 320F28026
Frequency 60MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series C2000? C28x Piccolo?
Packaging Tray
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 7mm
Length 7mm
Height 1.6mm
