TMS320F280260PTT
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 16KB FLASH 48LQFP
PDF
/
Buying Options
Total Price: USD $3.77
Unit Price: USD $3.772613
≥1 USD $3.772613
≥10 USD $3.559067
≥100 USD $3.357606
≥500 USD $3.167556
≥1000 USD $2.98826
Inventory: 1720
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 7mm
Length 7mm
Height 1.6mm
Technical
Number of External Interrupts 3
Number of Serial I/Os 3
Number of UART Channels 1
RAM (words) 6
Integrated Cache NO
Format FIXED-POINT
Low Power Mode YES
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x12b
Bit Size 32
Supply Current-Max 90mA
Connectivity I2C, SCI, SPI, UART/USART
Program Memory Size 16KB 8K x 16
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.71V~1.995V
RAM Size 3K x 16
Number of I/O 22
Oscillator Type Internal
Memory Size 16kB
Interface I2C, SCI, SPI, UART, USART
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number 320F280260
Frequency 50MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series C2000? C28x Piccolo?
Packaging Tube
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 48
Surface Mount YES
Package / Case 48-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
