TMS320F2801PZS
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
TEXAS INSTRUMENTS TMS320F2801PZS IC, DSP, 16K FLASH, 100-LQFP
PDF
/
Buying Options
Total Price: USD $18.82
Unit Price: USD $18.82056
≥1 USD $18.82056
≥10 USD $17.75524
≥100 USD $16.750231
≥500 USD $15.802108
≥1000 USD $14.907651
Inventory: 2469
Minimum: 1
-
+
Technical Details
Technical
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 32KB 16K x 16
Connectivity CANbus, I2C, SCI, SPI, UART/USART
Supply Current-Max 230mA
Bit Size 32
Data Converter A/D 16x12b
Data Bus Width 32b
PWM Channels 6
Density 256 kb
Core Architecture TMS320
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 16
Number of Programmable I/O 35
Peripherals POR, PWM, WDT
Core Processor C28x
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Voltage - Supply (Vcc/Vdd) 1.71V~1.89V
Memory Type EEPROM, FLASH
RAM Size 6K x 16
Oscillator Type Internal
Memory Size 32kB
Interface CAN, I2C, SCI, SPI, UART, USART
Operating Supply Voltage 1.8V
Pin Count 100
Base Part Number 320F2801
Frequency 100MHz
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
Additional Feature ALSO REQUIRES 3.3V SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 100
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100, C2000? C28x Fixed-Point
Packaging Tray
Operating Temperature -40°C~125°C TA
Internal Bus Architecture MULTIPLE
Barrel Shifter NO
Number of External Interrupts 3
Number of Timers 10
Number of UART Channels 1
Integrated Cache NO
Physical
Weight 635.596308mg
Number of Pins 100
Package / Case 100-LQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 14mm
Length 14mm
Height 1.6mm
