TM4C129ENCPDTI3R
RoHS
RoHS compliant
RoHS compliantPackage 128-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 128TQFP
PDF
/
Buying Options
Total Price: USD $15.78
Unit Price: USD $15.7784
≥1 USD $15.7784
≥10 USD $14.49976
≥100 USD $13.899072
≥500 USD $12.246256
≥1000 USD $11.645181
≥3000 USD $10.89389
Inventory: 1446
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 128-TQFP
Number of Pins 128
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series Tiva? C
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 128
Max Power Dissipation 904mW
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 1.2V
Terminal Pitch 0.4mm
Frequency 120MHz
Base Part Number M4C129
Supply Voltage-Max (Vsup) 1.32V
Supply Voltage-Min (Vsup) 1.14V
Interface CAN, EBI/EMI, Ethernet, I2C, IrDA, SPI, UART, USART, USB
Memory Size 1MB
Oscillator Type Internal
Number of I/O 90
RAM Size 256K x 8
Voltage - Supply (Vcc/Vdd) 2.97V~3.63V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 12
Core Processor ARM? Cortex?-M4F
Peripherals Brown-out Detect/Reset, DMA, Motion Control PWM, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 1MB 1M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, QEI, SPI, SSI, UART/USART, USB OTG
Supply Current-Max 42mA
Bit Size 32
Data Converter A/D 20x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Core Architecture ARM
EEPROM Size 6K x 8
CPU Family CORTEX-M4F
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 20
Number of Programmable I/O 90
Format FLOATING-POINT
Integrated Cache YES
RAM (words) 256
Number of UART Channels 8
Number of Serial I/Os 27
Number of Timers 8
Dimensions
Height 1.2mm
Length 14mm
Width 14mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
