TM4C123GH6ZRBT7
RoHS
RoHS compliant
RoHS compliantPackage 157-VFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 256KB FLASH 157BGA
PDF
/
Buying Options
Total Price: USD $15.39
Unit Price: USD $15.388102
≥1 USD $15.388102
≥10 USD $14.517079
≥100 USD $13.695358
≥500 USD $12.920147
≥1000 USD $12.188819
Inventory: 3605
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case 157-VFBGA
Surface Mount YES
Number of Pins 157
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Series Tiva? C
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 157
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.2V
Terminal Pitch 0.65mm
Frequency 80MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number M4C123
Pin Count 157
Supply Voltage-Max (Vsup) 1.32V
Interface CAN, I2C, IrDA, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 120
RAM Size 32K x 8
Voltage - Supply (Vcc/Vdd) 1.08V~3.63V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 12
Core Processor ARM? Cortex?-M4F
Peripherals Brown-out Detect/Reset, DMA, Motion PWM, POR, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity CANbus, I2C, IrDA, Microwire, QEI, SPI, SSI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 24x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
ROM (words) 262144
Core Architecture ARM
EEPROM Size 2K x 8
CPU Family CORTEX-M4F
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 24
Number of Programmable I/O 120
Format FLOATING-POINT
Integrated Cache YES
RAM (words) 32
Number of UART Channels 8
Number of Serial I/Os 21
Number of Timers 12
Dimensions
Height 1mm
Length 9mm
Width 9mm
Thickness 740μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
