TM4C123GH6PGEI7
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-Bit Tiva C ARM Cortex M4F RISC 256KB Flash 1.2V/3.3V 144-Pin LQFP
PDF
/
Buying Options
Total Price: USD $53.7
Unit Price: USD $53.6959
≥1 USD $53.6959
≥10 USD $44.05815
≥100 USD $42.6816
≥500 USD $41.30505
≥1000 USD $39.92755
Inventory: 1438
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.4mm
Width 20mm
Length 20mm
Height 1.6mm
Technical
Number of Timers 12
Number of Serial I/Os 21
Number of UART Channels 8
RAM (words) 32
Integrated Cache YES
Format FLOATING-POINT
Number of Programmable I/O 105
Number of A/D Converters 24
Low Power Mode YES
Boundary Scan YES
CPU Family CORTEX-M4F
EEPROM Size 2K x 8
Core Architecture ARM
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 24x12b
Bit Size 32
Supply Current-Max 54.9mA
Connectivity CANbus, I2C, IrDA, Microwire, QEI, SPI, SSI, UART/USART, USB OTG
Program Memory Size 256KB 256K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, Motion PWM, POR, WDT
Core Processor ARM? Cortex?-M4F
Number of Bits 12
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.08V~3.63V
RAM Size 32K x 8
Number of I/O 105
Oscillator Type Internal
Memory Size 256kB
Interface CAN, I2C, IrDA, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 3.15V
Supply Voltage-Max (Vsup) 3.63V
Pin Count 144
Base Part Number M4C123
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 80MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code 3A991A2
Number of Terminations 144
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Tiva? C
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 144
Surface Mount YES
Package / Case 144-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
Alternative Model
