TM4C123BH6PMIR
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant GULL WING QUAD Microcontroller -40C~85C TA 80MHz 1.6mm 32K x 8
PDF
/
Buying Options
Total Price: USD $36.48
Unit Price: USD $36.481589
≥1 USD $36.481589
≥10 USD $34.416585
≥100 USD $32.468482
≥500 USD $30.630641
≥1000 USD $28.896834
Inventory: 4379
Minimum: 1
-
+
Technical Details
Technical
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Number of UART Channels 8
Number of Programmable I/O 49
CPU Family CORTEX-M4F
On Chip Program ROM Width 8
EEPROM Size 2K x 8
Core Architecture ARM
ROM (words) 262144
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 12x12b
Bit Size 32
Connectivity CANbus, I2C, IrDA, Microwire, QEI, SPI, SSI, UART/USART
Program Memory Size 256KB 256K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, Motion PWM, POR, WDT
Core Processor ARM? Cortex?-M4F
Number of Bits 12
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.08V~3.63V
RAM Size 32K x 8
Number of I/O 43
Oscillator Type Internal
Memory Size 256kB
Interface CAN, I2C, I2S, IrDA, SPI, UART, USART, USB
Supply Voltage-Max (Vsup) 1.32V
Operating Supply Voltage 3.3V
Base Part Number M4C123
Frequency 80MHz
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Tiva? C
Physical
Number of Pins 64
Package / Case 64-LQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.6mm
