TM4C1230D5PMI
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 64LQFP
PDF
/
Buying Options
Total Price: USD $85.36
Unit Price: USD $85.3632
≥1 USD $85.3632
≥10 USD $82.60915
≥100 USD $79.8551
≥500 USD $71.59485
Inventory: 1601
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-LQFP
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series Tiva? C
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
ECCN Code 3A991.A.2
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.2V
Terminal Pitch 0.5mm
Frequency 80MHz
Base Part Number M4C1230
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 1.32V
Interface CAN, I2C, I2S, SPI, UART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 49
RAM Size 24K x 8
Voltage - Supply (Vcc/Vdd) 1.08V~3.63V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 12
Core Processor ARM? Cortex?-M4F
Peripherals Brown-out Detect/Reset, DMA, POR, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 64KB 64K x 8
Connectivity CANbus, I2C, IrDA, Microwire, SPI, SSI, UART/USART
Bit Size 32
Data Converter A/D 12x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Core Architecture ARM
EEPROM Size 2K x 8
Number of UART Channels 8
Number of I2C Channels 6
Number of SPI Channels 4
Dimensions
Height 1.45mm
Length 10.2mm
Width 10.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
