RM48L952ZWTT
RoHS
RoHS compliant
RoHS compliantPackage 337-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 3MB FLASH 337NFBGA
PDF
/
Inventory: 8556
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 337-LFBGA
Number of Pins 337
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Series Hercules? RM4 ARM? Cortex?-R4
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 337
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Microcontrollers
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.2V
Terminal Pitch 0.8mm
Frequency 220MHz
Base Part Number 48L952
Pin Count 337
Operating Supply Voltage 1.2V
Interface CAN, EBI/EMI, Ethernet, I2C, I2S, LIN, SCI, SPI, UART, USB
Memory Size 3MB
Oscillator Type External
Number of I/O 120
RAM Size 256K x 8
Voltage - Supply (Vcc/Vdd) 1.14V~1.32V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-R4F
Peripherals DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16/32-Bit
Program Memory Size 3MB 3M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, LINbus, MibSPI, SCI, SPI, UART/USART, USB
Supply Current-Max 400mA
Bit Size 32
Data Converter A/D 24x12b
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
Number of Timers/Counters 3
Core Architecture ARM
EEPROM Size 64K x 8
CPU Family CORTEX-R4F
Number of UART Channels 2
Number of ADC Channels 24
Number of I2C Channels 1
Dimensions
Height 950μm
Length 16.1mm
Width 16.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
