MSP432P411VIPZ
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 100LQFP
PDF
/
Inventory: 5274
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 432P411
Supply Voltage-Max (Vsup) 3.7V
Oscillator Type Internal
Number of I/O 84
Speed 48MHz
RAM Size 128K x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.7V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 14
Core Processor ARM? Cortex?-M4F
Peripherals DMA, LCD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 512KB 512K x 8
Connectivity I2C, IrDA, SPI, UART/USART
Supply Current-Max 8.2mA
Bit Size 32
Data Converter A/D 26x16b
Has ADC YES
DMA Channels YES
PWM Channels YES
Number of Timers/Counters 6
Boundary Scan YES
Low Power Mode YES
Format FLOATING-POINT
Integrated Cache NO
RAM (words) 128
Terminal Position QUAD
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP432?
Packaging Tray
Operating Temperature -40°C~85°C TA
Number of UART Channels 4
Number of ADC Channels 24
Number of Serial I/Os 8
Physical
Number of Pins 100
Surface Mount YES
Package / Case 100-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
Dimensions
Height 1.6mm
Length 14mm
Width 14mm
Thickness 1.4mm
Compliance
RoHS Status ROHS3 Compliant
