MSP430P315SIDL
RoHS
RoHS compliant
RoHS compliantPackage 48-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Contains Lead ROHS3Compliant GULL WING DUAL Microcontroller 3mus 3/5V -40C~85C TA 8MHz
PDF
/
Buying Options
Total Price: USD $17.1
Unit Price: USD $17.097941
≥1 USD $17.097941
≥10 USD $16.13013
≥100 USD $15.217102
≥500 USD $14.355762
≥1000 USD $13.543168
Inventory: 1500
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-BSSOP (0.295, 7.50mm Width)
Number of Pins 48
Weight 600.301152mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series MSP430x3xx
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.635mm
Reach Compliance Code unknown
Frequency 8MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 48
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3/5V
Interface UART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 14
Speed 3.3 MHz
RAM Size 512 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 16
Core Processor MSP430
Peripherals LCD, POR, WDT
Program Memory Type OTP
Core Size 16-Bit
Program Memory Size 16KB 16K x 8
Connectivity UART/USART
Bit Size 16
Data Converter Slope A/D
Access Time 3 μs
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 2
RAM (bytes) 512
Dimensions
Length 15.875mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
