MSP430I2041TRHBR
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 32KB FLASH 32VQFN
PDF
/
Buying Options
Total Price: USD $3.13
Unit Price: USD $3.1328
≥1 USD $3.1328
≥10 USD $2.81336
≥100 USD $2.659712
≥500 USD $2.305248
≥1000 USD $2.186976
≥3000 USD $1.962382
Inventory: 1562
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-VFQFN Exposed Pad
Number of Pins 32
Weight 72.206235mg
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Series MSP430I2xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 32
ECCN Code EAR99
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Frequency 16.384MHz
Base Part Number MSP430
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, IrDA, SCI, SPI, UART, USART
Memory Size 32kB
Oscillator Type External
Number of I/O 16
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 2.2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Peripherals Brown-out Detect/Reset, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 32KB 32K x 8
Connectivity I2C, IrDA, SCI, SPI, UART/USART
Bit Size 16
Data Converter A/D 4x24b Sigma-Delta
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
Number of Timers/Counters 2
Low Power Mode YES
Format FIXED-POINT
Integrated Cache NO
RAM (words) 2
Number of UART Channels 1
Number of ADC Channels 4
Number of Serial I/Os 1
Dimensions
Height 1mm
Length 5mm
Width 5mm
Thickness 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
