MSP430G2252TDA1
RoHS
RoHS compliant
RoHS compliantPackage Die
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MIXED SIGNAL MICROCONTROLLER
PDF
/
Inventory: 1695
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Integrated Cache NO
Format FLOATING-POINT
Low Power Mode YES
ROM (words) 0
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Data Converter A/D 8x10b
Bit Size 16
Connectivity I2C, SPI, USI
Program Memory Size 2KB 2K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
Memory Type FLASH, ROMless
RAM Size 256 x 8
Number of I/O 16
Oscillator Type Internal
Memory Size 2kB
Interface I2C, SPI
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code R-XUUC-N22
Frequency 16MHz
Supply Voltage 2.5V
Terminal Position UPPER
Technology CMOS
Number of Terminations 22
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MSP430G2xx
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 0
Surface Mount YES
Package / Case Die
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 35 Weeks
