MSP430G2202IPW20R
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MSP430G2x32, MSP430G2x02 Mixed Signal Microcontroller 20-TSSOP -40 to 85
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.27688
≥100 USD $1.211936
≥500 USD $0.995544
≥1000 USD $0.930618
≥3000 USD $0.822413
Inventory: 1235
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430G2xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.2V
Frequency 16MHz
Pin Count 20
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Interface I2C, SPI
Memory Size 2kB
Oscillator Type Internal
Number of I/O 16
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 2KB 2K x 8
Connectivity I2C, SPI, USI
Bit Size 16
Watchdog Timer Yes
Has ADC NO
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 1
Boundary Scan YES
Low Power Mode YES
Number of Programmable I/O 16
Format FIXED-POINT
Integrated Cache NO
Number of UART Channels 0
RAM (bytes) 256
Dimensions
Height 1.2mm
Length 6.5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
