MSP430G2153IN20
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED-POINT Lead Free ROHS3Compliant DUAL Microcontroller -40C~85C TA 16MHz 5.08mm 256x 8
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4344
≥1 USD $1.4344
≥10 USD $1.28656
≥100 USD $1.21374
≥500 USD $1.034088
≥1000 USD $0.970948
≥3000 USD $0.854691
Inventory: 417
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 4.57mm
Width 6.35mm
Length 24.33mm
Height 5.08mm
Technical
Number of SPI Channels 2
Number of GPIO 24
Number of I2C Channels 1
Number of Timers 2
Number of Serial I/Os 1
RAM (bytes) 256
Integrated Cache NO
Format FIXED-POINT
Number of A/D Converters 8
Low Power Mode YES
Boundary Scan YES
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 1KB 1K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 256 x 8
Number of I/O 16
Oscillator Type Internal
Memory Size 1kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Supply Voltage-Min (Vsup) 3.3V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 20
Frequency 16MHz
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430G2xx
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 20
Surface Mount NO
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
