MSP430G2113IRHB32T
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant NO LEAD QUAD Microcontroller -40C~85C TA 16MHz 0.5mm 256x 8
PDF
/
Inventory: 5051
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 32
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e4
Series MSP430G2xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
RAM (bytes) 256
Number of Timers/Counters 2
Data Bus Width 16b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 1KB 1K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 256 x 8
Number of I/O 24
Oscillator Type Internal
Memory Size 1kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Qualification Status Not Qualified
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 16MHz
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
