MSP430FR69721IRGCR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant NO LEAD QUAD Microcontroller -40C~85C TA 16MHz 1mm 2K x 8
PDF
/
Inventory: 8220
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 880μm
Width 9mm
Length 9mm
Height 1mm
Technical
Number of UART Channels 2
Low Power Mode YES
Boundary Scan YES
ROM (words) 65536
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 8x12b
Bit Size 16
Connectivity I2C, IrDA, SCI, SPI, UART/USART
Program Memory Size 64KB 64K x 8
Core Size 16-Bit
Program Memory Type FRAM
Peripherals Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT
Core Processor CPUXV2
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 2K x 8
Number of I/O 51
Oscillator Type Internal
Memory Size 64kB
Interface I2C, IrDA, SCI, SPI, UART, USART
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 64
Base Part Number MSP430
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 16MHz
Terminal Pitch 0.5mm
Supply Voltage 2.2V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430? FRAM
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
