MSP430FR5729IDAR
RoHS
RoHS compliant
RoHS compliantPackage 38-TSSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 16KB FRAM 38TSSOP
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2208
≥1 USD $3.2208
Inventory: 1649
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.15mm
Width 6.2mm
Length 12.5mm
Height 1.2mm
Technical
Number of SPI Channels 3
Number of GPIO 33
Number of I2C Channels 1
Number of Serial I/Os 2
Number of UART Channels 2
RAM (words) 1
Integrated Cache 0
Format FIXED-POINT
Number of A/D Converters 14
Low Power Mode YES
Boundary Scan YES
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 14x10b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 16KB 16K x 8
Core Size 16-Bit
Program Memory Type FRAM
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor CPUXV2
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~3.6V
Memory Type FRAM, ROMless
RAM Size 1K x 8
Number of I/O 30
Oscillator Type Internal
Memory Size 16kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Supply Voltage-Min (Vsup) 2V
Pin Count 38
Base Part Number MSP430
Frequency 8MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 38
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430? FRAM
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 38
Surface Mount YES
Package / Case 38-TSSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
