MSP430FR5723IRHAR
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU Mixed Signal MCU
PDF
/
Inventory: 8589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 40
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430? FRAM
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of GPIO 33
Number of Serial I/Os 2
Number of UART Channels 2
RAM (words) 1
Integrated Cache 0
Format FIXED-POINT
Low Power Mode YES
Boundary Scan YES
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Bit Size 16
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 8KB 8K x 8
Core Size 16-Bit
Program Memory Type FRAM
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor CPUXV2
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~3.6V
Memory Type FRAM, ROMless
RAM Size 1K x 8
Number of I/O 32
Oscillator Type Internal
Memory Size 8kB
Interface I2C, SPI, UART
Operating Supply Voltage 3.6V
Pin Count 40
Base Part Number MSP430
Frequency 8MHz
Supply Voltage 3V
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 6mm
Length 6mm
Height 1mm
