MSP430FR50431IRGCR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 16BIT
PDF
/
Inventory: 6618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430? FRAM
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3
Number of Terminations 64
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3V
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Base Part Number MSP430
JESD-30 Code S-PQCC-N64
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 44
Speed 16MHz
RAM Size 12K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor CPUXV2
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 24MHz
Program Memory Type FRAM
Core Size 16-Bit
Program Memory Size 64KB 64K x 8
Connectivity IrDA, SCI, SPI, UART/USART
Bit Size 16
Data Converter A/D 9x12b SAR
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
ROM (words) 65536
On Chip Program ROM Width 8

Dimensions

Length 9mm
Width 9mm

Compliance

RoHS Status RoHS Compliant
