MSP430FR2676TRHBT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description MICROCONTROLLER 16BIT
PDF
/
Inventory: 8882
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 5mm
Length 5mm
Height Seated (Max) 1mm

Technical

On Chip Data RAM Width 16
Number of Timers 5
Number of Serial I/Os 2
RAM (bytes) 8192
RAM (words) 4096
Integrated Cache NO
Format FLOATING-POINT
Low Power Mode YES
Boundary Scan YES
On Chip Program ROM Width 8
ROM (words) 65536
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 8x12b SAR
Bit Size 16
Supply Current-Max 3.75mA
Connectivity I2C, IrDA, SCI, SPI, UART/USART
Program Memory Size 64.5KB 64.5K x 8
Core Size 16-Bit
Program Memory Type FRAM
Clock Frequency 0.032MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 8K x 8
Speed 16MHz
Number of I/O 27
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQCC-N32
Terminal Pitch 0.5mm
Supply Voltage 3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 32
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430? FRAM
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA

Physical

Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 6 Weeks
