MSP430FR2512IPW16
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 7.5KB FRAM 16TSSOP
PDF
/
Buying Options
Total Price: USD $2.05
Unit Price: USD $2.0504
≥1 USD $2.0504
≥10 USD $1.84448
≥100 USD $1.482307
≥500 USD $1.39187
≥1000 USD $1.217867
≥3000 USD $1.009096
Inventory: 388
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series MSP430? FRAM
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3V
Supply Voltage-Max (Vsup) 3.6V
Oscillator Type Internal
Number of I/O 11
Speed 16MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, Cap Sense, POR, PWM, WDT
Program Memory Type FRAM
Core Size 16-Bit
Program Memory Size 7.5KB 7.5K x 8
Connectivity I2C, IrDA, SCI, SPI, UART/USART
Bit Size 16
Data Converter A/D 5x10b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
ROM (words) 7680
Number of UART Channels 1
RAM (bytes) 2048
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
