MSP430FR2353TPT
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING QUAD CMOS Microcontroller -40C~105C TA 24MHz 1.6mm 2K x 8
PDF
/
Buying Options
Total Price: USD $2.54
Unit Price: USD $2.536106
≥1 USD $2.536106
≥10 USD $2.392551
≥100 USD $2.257124
≥500 USD $2.129363
≥1000 USD $2.008833
Inventory: 1102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 48-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Series MSP430? FRAM
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3V
Terminal Pitch 0.5mm
Base Part Number MSP430
JESD-30 Code S-PQFP-G48
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 44
Speed 24MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor CPU16
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 24MHz
Program Memory Type FRAM
Core Size 16-Bit
Program Memory Size 16KB 16K x 8
Connectivity I2C, IrDA, SPI, UART/USART
Bit Size 16
Data Converter A/D 12x12b; D/A 4x12b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
ROM (words) 16896
On Chip Program ROM Width 8
Dimensions
Height Seated (Max) 1.6mm
Length 7mm
Width 7mm
Compliance
RoHS Status ROHS3 Compliant
