MSP430FG4270IDL
RoHS
RoHS compliant
RoHS compliantPackage 48-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED-POINT Lead Free ROHS3Compliant GULL WING Microcontroller -40C~85C TA 8MHz 2.79mm 256x 8
PDF
/
Buying Options
Total Price: USD $21.15
Unit Price: USD $21.154372
≥1 USD $21.154372
≥10 USD $19.956956
≥100 USD $18.827307
≥500 USD $17.761615
≥1000 USD $16.756241
Inventory: 1405
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.59mm
Width 7.49mm
Length 15.88mm
Height 2.79mm
Technical
RAM (bytes) 256
Number of UART Channels 0
Integrated Cache NO
Format FIXED-POINT
Number of Programmable I/O 32
Number of A/D Converters 5
Low Power Mode YES
Boundary Scan YES
Number of Timers/Counters 2
DAC Channels YES
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Data Converter A/D 5x16b; D/A 1x12b
Bit Size 16
Program Memory Size 32KB 32K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, LCD, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 256 x 8
Number of I/O 32
Oscillator Type Internal
Memory Size 32kB
Interface UART
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 48
Frequency 8MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430x4xx
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 600.301152mg
Number of Pins 48
Surface Mount YES
Package / Case 48-BSSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 12 Weeks
