MSP430FE427AIPMR
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED-POINT Lead Free ROHS3Compliant GULL WING Microcontroller -40C~85C TA 0.5mA 8MHz 1.6mm
PDF
/
Buying Options
Total Price: USD $6.63
Unit Price: USD $6.63385
≥1 USD $6.63385
≥10 USD $5.4435
≥100 USD $5.27345
≥500 USD $5.10245
≥1000 USD $4.9324
Inventory: 1803
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 10mm
Length 10mm
Height 1.6mm
Technical
Number of Timers 4
Number of Serial I/Os 1
Number of UART Channels 1
RAM (words) 1
Integrated Cache NO
Format FIXED-POINT
Number of Programmable I/O 14
Number of A/D Converters 3
Low Power Mode YES
Boundary Scan YES
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 3x16b
Bit Size 16
Supply Current-Max 0.5mA
Connectivity SPI, UART/USART
Program Memory Size 32KB 32K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, LCD, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 1K x 8
Speed 8.4 MHz
Number of I/O 14
Oscillator Type Internal
Memory Size 32kB
Interface SPI, UART, USART
Supply Voltage-Min (Vsup) 2.7V
Pin Count 64
Frequency 8MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
ECCN Code EAR99
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430x4xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 342.689036mg
Number of Pins 64
Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
