MSP430F5636IZQWT
RoHS
RoHS compliant
RoHS compliantPackage 113-VFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant BALL BOTTOM Microcontroller -40C~85C TA 20MHz 1mm 18K x 8
PDF
/
Buying Options
Total Price: USD $55.89
Unit Price: USD $55.88945
≥1 USD $55.88945
≥10 USD $45.8584
≥100 USD $44.4258
≥500 USD $42.99225
≥1000 USD $41.55965
Inventory: 1158
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7mm
Height Seated (Max) 1mm
Technical
Number of UART Channels 2
Number of A/D Converters 16
On Chip Program ROM Width 8
Number of Timers/Counters 4
DAC Channels YES
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x12b; D/A 2x12b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART, USB
Program Memory Size 128KB 128K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor CPUXV2
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 18K x 8
Number of I/O 74
Oscillator Type Internal
Memory Size 128kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART, USB
Supply Voltage-Max (Vsup) 3.6V
Pin Count 113
Base Part Number MSP430
Frequency 20MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Microcontrollers
Additional Feature ALSO OPERATES 1.8V AT 8 MHZ
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 113
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series MSP430F5xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 113
Surface Mount YES
Package / Case 113-VFBGA
Mounting Type Surface Mount
