MSP430F5437IPN
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 256KB FLASH 80LQFP
PDF
/
Buying Options
Total Price: USD $8.86
Unit Price: USD $8.8616
≥1 USD $8.8616
≥10 USD $8.14528
≥100 USD $7.808064
≥500 USD $7.430526
Inventory: 427
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 80-LQFP
Number of Pins 80
Weight 465.697616mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series MSP430F5xx
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 80
Termination SMD/SMT
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 18MHz
Base Part Number MSP430
Pin Count 80
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Memory Size 256kB
Oscillator Type Internal
Number of I/O 67
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 2.2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor CPUXV2
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 256KB 256K x 8
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Supply Current-Max 5.56mA
Bit Size 16
Data Converter A/D 16x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
DAC Channels NO
Number of Timers/Counters 3
Density 2 Mb
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 16
Format FIXED-POINT
Integrated Cache NO
RAM (words) 16
Number of Serial I/Os 3
Number of PWM Channels 15
Number of I2C Channels 2
Number of SPI Channels 4
Dimensions
Height 1.6mm
Length 12mm
Width 12mm
Thickness 1.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
