MSP430F5418AIPN

Texas Instruments
RoHS
RoHS RoHS compliant
Package 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description MCU 16-bit MSP430 MSP430 RISC 128KB Flash 2.5V/3.3V 80-Pin LQFP Tray
PDF
/
Buying Options
Total Price: USD $3.09
Unit Price: USD $3.08845
≥1 USD $3.08845
≥10 USD $2.53365
≥100 USD $2.4548
≥500 USD $2.375
≥1000 USD $2.29615
Inventory: 15005
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Thickness 1.4mm
Width 12mm
Length 12mm
Height 1.6mm

Technical

Number of USB Channels 1
Number of SPI Channels 4
Number of I2C Channels 2
Number of Serial I/Os 3
RAM (words) 16
Integrated Cache NO
Format FIXED-POINT
Number of A/D Converters 16
Low Power Mode YES
Boundary Scan YES
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x12b
Bit Size 16
Supply Current-Max 9.6mA
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 128KB 128K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor CPUXV2
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 16K x 8
Number of I/O 67
Oscillator Type Internal
Memory Size 128kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Pin Count 80
Base Part Number MSP430
Frequency 25MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
ECCN Code EAR99
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430F5xx
Packaging Tube
Operating Temperature -40°C~85°C TA

Physical

Weight 639.990485mg
Number of Pins 80
Surface Mount YES
Package / Case 80-LQFP
Mounting Type Surface Mount
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
