MSP430F5232IRGZT
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit MSP430 RISC 64KB Flash 3.3V 48-Pin VQFN EP T/R
PDF
/
Buying Options
Total Price: USD $5.16
Unit Price: USD $5.1568
≥1 USD $5.1568
≥10 USD $4.63056
≥100 USD $4.377472
≥500 USD $3.793856
Inventory: 816
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Number of Pins 48
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430F5xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 25MHz
Base Part Number MSP430
Pin Count 48
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.8V
Interface I2C, IrDA, SPI, UART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 37
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
Core Processor CPUXV2
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 64KB 64K x 8
Connectivity I2C, IrDA, SPI, UART/USART
Supply Current-Max 11mA
Bit Size 16
Watchdog Timer Yes
Has ADC NO
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
ROM (words) 65536
Core Architecture RISC
Boundary Scan YES
Low Power Mode YES
Integrated Cache NO
Max Junction Temperature (Tj) 85°C
Number of External Interrupts 16
Number of I2C Channels 2
Ambient Temperature Range High 85°C
Number of SPI Channels 4
Dimensions
Height 1mm
Length 7mm
Width 7mm
Thickness 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
