MSP430F47196IPZR
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 120KB FLASH 100LQFP
PDF
/
Inventory: 6497
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Technology CMOS
Subcategory Microcontrollers
Additional Feature IT ALSO OPERATES 4.15MHZ AT MINI 1.8V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430x4xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Number of Timers 7
Number of Serial I/Os 2
Number of UART Channels 2
RAM (words) 4
Integrated Cache NO
Format FIXED-POINT
Number of Programmable I/O 68
Number of A/D Converters 6
Low Power Mode YES
Boundary Scan YES
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 6x16b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 120KB 120K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 4K x 8
Number of I/O 68
Oscillator Type Internal
Memory Size 120kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Supply Voltage-Min (Vsup) 3.3V
Pin Count 100
Frequency 16MHz
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Physical
Number of Pins 100
Surface Mount YES
Package / Case 100-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 8 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 14mm
Length 14mm
Height 1.6mm
