MSP430F435IPN
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-Bit MSP430 RISC 16KB Flash 2.5V/3.3V 80-Pin LQFP
PDF
/
Buying Options
Total Price: USD $10.31
Unit Price: USD $10.3136
≥1 USD $10.3136
≥10 USD $9.31744
≥100 USD $8.884128
≥500 USD $7.714124
≥1000 USD $7.367448
≥3000 USD $6.717374
Inventory: 672
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case 80-LQFP
Surface Mount YES
Number of Pins 80
Weight 465.697616mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series MSP430x4xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 80
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 8MHz
Pin Count 80
Interface SPI, UART, USART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 48
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, LCD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 16KB 16K x 8 + 256B
Connectivity SPI, UART/USART
Supply Current-Max 0.56mA
Bit Size 16
Data Converter A/D 8x12b
Watchdog Timer Yes
Access Time 8 μs
Has ADC NO
DMA Channels NO
Data Bus Width 16b
DAC Channels NO
Density 128 kb
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 8
Format FIXED-POINT
Integrated Cache NO
RAM (words) 0.5
Number of UART Channels 1
RAM (bytes) 512
Number of Serial I/Os 1
Number of Timers 7
Number of PWM Channels 3
Number of SPI Channels 2
Dimensions
Height 1.6mm
Length 12mm
Width 12mm
Thickness 1.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
