MSP430F249TPMR
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 60KB FLASH 64LQFP
PDF
/
Buying Options
Total Price: USD $4.29
Unit Price: USD $4.29242
≥1 USD $4.29242
≥10 USD $4.04945
≥100 USD $3.82024
≥500 USD $3.604
≥1000 USD $3.4
≥3000 USD $3.20755
Inventory: 103912
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 10mm
Length 10mm
Height 1.6mm
Technical
Number of Timers 6
Number of Serial I/Os 4
Number of UART Channels 2
RAM (words) 2
Integrated Cache NO
Format FIXED-POINT
Number of Programmable I/O 48
Number of A/D Converters 8
Low Power Mode YES
Boundary Scan YES
ROM (words) 61440
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x12b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 60KB 60K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 2K x 8
Number of I/O 48
Oscillator Type Internal
Memory Size 60kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Pin Count 64
Frequency 16MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
ECCN Code EAR99
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430F2xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
Physical
Weight 342.689036mg
Number of Pins 64
Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
