MSP430F2417TPN
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU 16B Ultra-Lo-Pwr MCU
PDF
/
Buying Options
Total Price: USD $6.91
Unit Price: USD $6.91315
≥1 USD $6.91315
≥10 USD $5.67245
≥100 USD $5.4948
≥500 USD $5.31715
≥1000 USD $5.14045
Inventory: 1285
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 80-LQFP
Surface Mount YES
Number of Pins 80
Weight 465.697616mg
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Series MSP430F2xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 80
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Frequency 16MHz
Pin Count 80
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3.3V
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Memory Size 92kB
Oscillator Type Internal
Number of I/O 64
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 92KB 92K x 8 + 256B
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Supply Current-Max 0.595mA
Bit Size 16
Data Converter A/D 8x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 8
Format FIXED-POINT
Integrated Cache NO
RAM (words) 8
Number of Serial I/Os 2
Number of GPIO 48
Dimensions
Height 1.6mm
Length 12mm
Width 12mm
Thickness 1.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
