MSP430F2370IRHAT
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Ultra-Low-Power Microcontroller, 32KB Flash, 2048B RAM, Comparator 40-VQFN -40 to 85
PDF
/
Buying Options
Total Price: USD $5.76
Unit Price: USD $5.7552
≥1 USD $5.7552
≥10 USD $5.20168
≥100 USD $4.960032
≥500 USD $4.306632
Inventory: 1202
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 900μm
Width 6mm
Length 6mm
Height 1mm
Technical
Number of SPI Channels 2
Number of I2C Channels 1
Number of PWM Channels 3
Number of Timers 2
Number of Serial I/Os 1
RAM (words) 2
Integrated Cache NO
Format FIXED-POINT
Low Power Mode YES
Boundary Scan YES
DAC Channels NO
Data Bus Width 16b
DMA Channels NO
Has ADC NO
Watchdog Timer Yes
Data Converter Slope A/D
Bit Size 16
Supply Current-Max 0.55mA
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 32KB 32K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 2K x 8
Number of I/O 32
Oscillator Type Internal
Memory Size 32kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Pin Count 40
Frequency 16MHz
Terminal Pitch 0.5mm
Supply Voltage 2.2V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430F2xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 103.986051mg
Number of Pins 40
Surface Mount YES
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
