MSP430F2330IYFFR
RoHS
RoHS compliant
RoHS compliantPackage 49-UFBGA, DSBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant BALL BOTTOM Microcontroller -40C~85C TA 0.55mA 16MHz 0.4mm
PDF
/
Buying Options
Total Price: USD $2.13
Unit Price: USD $2.132084
≥1 USD $2.132084
≥10 USD $2.011393
≥100 USD $1.897547
≥500 USD $1.790137
≥1000 USD $1.68881
Inventory: 1118
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 49-UFBGA, DSBGA
Surface Mount YES
Number of Pins 49
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430F2xx
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 49
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Microcontrollers
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Terminal Pitch 0.4mm
Frequency 16MHz
Pin Count 49
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Memory Size 8kB
Oscillator Type Internal
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 8KB 8K x 8 + 256B
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Supply Current-Max 0.55mA
Bit Size 16
Data Converter Slope A/D
Watchdog Timer Yes
Data Bus Width 16b
Number of Timers/Counters 2
Number of Programmable I/O 32
Number of UART Channels 1
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
