MSP430F2254TRHAR
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU 16-bit Ultra-Lo-Pwr Microcontroller
PDF
/
Buying Options
Total Price: USD $4.5
Unit Price: USD $4.5011
≥1 USD $4.5011
≥10 USD $3.69265
≥100 USD $3.5777
≥500 USD $3.4618
≥1000 USD $3.34685
Inventory: 1576
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 40
Weight 103.986051mg
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Series MSP430F2xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology BIPOLAR
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.2V
Terminal Pitch 0.5mm
Frequency 16MHz
Pin Count 40
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3.3V
Interface I2C, IrDA, LIN, SCI, SPI, UART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 32
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 16KB 16K x 8 + 256B
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Supply Current-Max 0.55mA
Bit Size 16
Data Converter A/D 12x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 12
Number of Programmable I/O 32
Format FIXED-POINT
Integrated Cache NO
RAM (words) 0.5
Number of UART Channels 1
RAM (bytes) 512
Number of Serial I/Os 2
Dimensions
Height 1mm
Length 6mm
Width 6mm
Thickness 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
