MSP430F2254IYFFT
RoHS
RoHS compliant
RoHS compliantPackage 49-UFBGA, DSBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant BALL BOTTOM Microcontroller -40C~85C TA 0.55mA 16MHz 0.4mm
PDF
/
Inventory: 5363
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
RAM (bytes) 512
Number of UART Channels 1
Number of Programmable I/O 32
Number of A/D Converters 12
Number of Timers/Counters 2
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 12x10b
Bit Size 16
Supply Current-Max 0.55mA
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 16KB 16K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 512 x 8
Number of I/O 32
Oscillator Type Internal
Memory Size 16kB
Interface I2C, SCI, SPI, UART
Supply Voltage-Min (Vsup) 3.3V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 49
Frequency 16MHz
Terminal Pitch 0.4mm
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 49
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series MSP430F2xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 49
Surface Mount YES
Package / Case 49-UFBGA, DSBGA
Mounting Type Surface Mount
