MSP430F2252TDA
RoHS
RoHS compliant
RoHS compliantPackage 38-TSSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED-POINT Lead Free ROHS3Compliant GULL WING Microcontroller -40C~105C TA 0.55mA 16MHz 1.2mm
PDF
/
Buying Options
Total Price: USD $5.73
Unit Price: USD $5.7288
≥1 USD $5.7288
≥10 USD $5.14888
≥100 USD $4.8675
≥500 USD $4.2185
≥1000 USD $4.002178
≥3000 USD $3.591148
Inventory: 168
Minimum: 1
-
+
Technical Details
Technical
Bit Size 16
Supply Current-Max 0.55mA
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Program Memory Size 16KB 16K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor MSP430
Number of Bits 16
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 512 x 8
Number of I/O 32
Oscillator Type Internal
Memory Size 16kB
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Supply Voltage-Min (Vsup) 3.3V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 38
Frequency 16MHz
Terminal Pitch 0.65mm
Supply Voltage 2.2V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 38
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430F2xx
Packaging Tube
Operating Temperature -40°C~105°C TA
Number of Serial I/Os 2
RAM (bytes) 512
Number of UART Channels 1
RAM (words) 0.5
Integrated Cache NO
Format FIXED-POINT
Number of Programmable I/O 32
Number of A/D Converters 12
Low Power Mode YES
Boundary Scan YES
Number of Timers/Counters 2
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 12x10b
Physical
Weight 203.804722mg
Number of Pins 38
Surface Mount YES
Package / Case 38-TSSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.15mm
Width 6.2mm
Length 12.5mm
Height 1.2mm
