MSP430F2112IPWR
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED-POINT Lead Free ROHS3Compliant GULL WING Microcontroller -40C~85C TA 16MHz 1.2mm 256x 8
PDF
/
Buying Options
Total Price: USD $2.61
Unit Price: USD $2.6136
≥1 USD $2.6136
≥10 USD $2.34608
≥100 USD $2.213376
≥500 USD $1.885752
≥1000 USD $1.770666
≥3000 USD $1.549328
Inventory: 856
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 28
Weight 117.508773mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430F2xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.65mm
Frequency 16MHz
Pin Count 28
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3.3V
Interface I2C, IrDA, LIN, SCI, SPI, UART, USART
Memory Size 2kB
Oscillator Type Internal
Number of I/O 24
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 2KB 2K x 8 + 256B
Connectivity I2C, IrDA, LINbus, SCI, SPI, UART/USART
Bit Size 16
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 8
Number of Programmable I/O 24
Format FIXED-POINT
Integrated Cache NO
Number of UART Channels 1
RAM (bytes) 256
Number of Serial I/Os 1
Dimensions
Height 1.2mm
Length 9.7mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
