MSP430F2111IRGER
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 2KB FLASH 24VQFN
PDF
/
Buying Options
Total Price: USD $2.14
Unit Price: USD $2.1384
≥1 USD $2.1384
≥10 USD $1.92192
≥100 USD $1.813152
≥500 USD $1.54484
≥1000 USD $1.450522
≥3000 USD $1.269206
Inventory: 1185
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 24
Weight 45.387587mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430F2xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 24
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 16MHz
Pin Count 24
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Supply Voltage-Min (Vsup) 3.3V
Interface UART
Memory Size 2kB
Oscillator Type Internal
Number of I/O 16
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 2KB 2K x 8 + 256B
Bit Size 16
Data Converter Slope A/D
Watchdog Timer Yes
Has ADC NO
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 1
Boundary Scan YES
Low Power Mode YES
Number of Programmable I/O 16
Format FIXED-POINT
Integrated Cache NO
Number of UART Channels 0
RAM (bytes) 128
Dimensions
Height 1mm
Length 4mm
Width 4mm
Thickness 880μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
