MSP430F147IPM
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit MSP430 MSP430 RISC 32KB Flash 2.5V/3.3V 64-Pin LQFP Tray
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.83265
≥1 USD $4.83265
≥10 USD $3.9653
≥100 USD $3.8418
≥500 USD $3.71735
≥1000 USD $3.59385
Inventory: 21572
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 10mm
Length 10mm
Height 1.6mm
Technical
Number of Serial I/Os 2
RAM (words) 1
Integrated Cache NO
Format FIXED-POINT
Number of Programmable I/O 48
Number of A/D Converters 8
Low Power Mode YES
Boundary Scan YES
Density 256 kb
Address Bus Width 16b
Number of Timers/Counters 2
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Access Time 8 μs
Watchdog Timer Yes
Data Converter A/D 8x12b
Bit Size 16
Supply Current-Max 0.56mA
Connectivity SPI, UART/USART
Program Memory Size 32KB 32K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals POR, PWM, WDT
Core Processor MSP430
Number of Bits 16
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 1K x 8
Number of I/O 48
Oscillator Type Internal
Memory Size 32kB
Interface SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Pin Count 64
Frequency 8MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430x1xx
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Weight 342.689036mg
Number of Pins 64
Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
