MSP430F133IPM
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit MSP430 MSP430 RISC 8KB Flash 2.5V/3.3V 64-Pin LQFP Tray
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7127
≥1 USD $6.7127
≥10 USD $5.5081
≥100 USD $5.3352
≥500 USD $5.16325
≥1000 USD $4.9913
Inventory: 18504
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 64-LQFP
Surface Mount YES
Number of Pins 64
Weight 342.689036mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series MSP430x1xx
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Termination SMD/SMT
ECCN Code EAR99
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 8MHz
Pin Count 64
Supply Voltage-Max (Vsup) 3.6V
Interface SPI, UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 48
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
Number of Bits 12
Core Processor MSP430
Peripherals POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 8KB 8K x 8 + 256B
Connectivity SPI, UART/USART
Supply Current-Max 0.56mA
Bit Size 16
Data Converter A/D 8x12b
Watchdog Timer Yes
Access Time 8 μs
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
Address Bus Width 16b
Density 64 kb
ROM (words) 4096
Core Architecture RISC
Boundary Scan YES
Low Power Mode YES
Number of A/D Converters 8
Number of Programmable I/O 48
Format FIXED-POINT
Integrated Cache NO
Number of UART Channels 1
Number of Serial I/Os 2
RAM (bytes) 256
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 10mm
Length 10mm
Height 1.6mm
