MSP430F122IDWR
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant GULL WING DUAL Microcontroller 2/3.3V -40C~85C TA 8MHz 2.65mm
PDF
/
Buying Options
Total Price: USD $2.48
Unit Price: USD $2.482323
≥1 USD $2.482323
≥10 USD $2.341804
≥100 USD $2.209249
≥500 USD $2.084204
≥1000 USD $1.966228
Inventory: 5166
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 28
Weight 730.794007mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430x1xx
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.2V
Frequency 8MHz
Pin Count 28
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Interface SPI, UART, USART
Memory Size 4kB
Oscillator Type Internal
Number of I/O 22
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 4KB 4K x 8 + 256B
Connectivity SPI, UART/USART
Bit Size 16
Data Converter Slope A/D
Watchdog Timer Yes
Has ADC NO
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
ROM (words) 4096
Number of Programmable I/O 22
Number of UART Channels 1
RAM (bytes) 256
Dimensions
Height Seated (Max) 2.65mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
